Qualidade Fita da isolação do transformador & Fita da isolação da tela Fábrica da China

Qualidade Fita da isolação do transformador & Fita da isolação da tela Fábrica

Yellow Mylar Tape for High-Frequency Transformer Automatic Winding 5 mm × 132 m PET Electrical Insulation Tape with Flat and Dense Winding Customer Application Industry: Transformer ManufacturingApplication: High-Frequency Transformer InsulationProduct: Yellow Mylar Electrical Insulation TapeSpecification: 5 mm × 132 mColor: YellowApplication Method: Automatic Winding Machine Project Overview A transformer manufacturer required yellow Mylar electrical insulation tape for the automatic winding process of high-frequency transformers. Because the tape was used on an automatic winding machine, the customer had specific requirements for the flatness and winding density of the finished tape rolls. The tape needed to remain flat when placed on a horizontal surface and maintain a dense, uniform winding structure without visible gaps between the tape layers. LY supplied customized 5 mm × 132 m yellow Mylar tape according to the customer’s application requirements. Customer Requirements The customer had two key requirements for the finished tape rolls. 1. Excellent Roll Flatness After the tape was slit and rewound into finished rolls, the roll needed to maintain a flat and stable shape. When placed on a horizontal surface, the finished roll should fit closely against the surface without obvious deformation, lifting or warping. This was important because the tape roll needed to maintain a stable shape during automatic machine operation. 2. Dense and Uniform Winding The customer also required a high and consistent winding density. There could be no obvious gaps between the tape layers, as loose winding could affect the tape’s performance during automatic application. The finished roll needed to have a compact and uniform winding structure from the inner layer to the outer layer. The Challenge The customer’s automatic winding machine included a fan that directed airflow toward the tape during the production process. If there were gaps between the tape layers, the airflow could cause these gaps to become larger. As the gaps expanded, part of the tape could lift or protrude from the roll surface. This created a potential problem during automatic application: Gap between tape layers → Airflow enlarges the gap → Tape layer protrudes → Tape becomes caught between two machine rollers Once the protruding tape became caught between the two rollers, it could interfere with the automatic winding process and affect machine operation. Therefore, the customer required not only suitable adhesive and insulation performance, but also high winding density and excellent roll flatness. Our Solution Based on the customer’s automatic machine application, LY focused on optimizing the rewinding and slitting process to achieve the required finished-roll quality. The key control points included: Roll Flatness Control The rewinding process was controlled to help maintain a flat and stable finished roll. The finished rolls were checked on a horizontal surface to verify that the roll maintained good contact with the surface without obvious deformation or warping. Winding Density Control The rewinding process was controlled to maintain a dense and uniform winding structure. Particular attention was given to preventing loose winding and visible gaps between tape layers. A compact winding structure helps reduce the possibility of airflow entering between the tape layers during automatic machine operation. Slitting Quality Control The tape was precision slit to the customer’s required 5 mm width. The slitting process was controlled to maintain consistent tape width and clean edges, helping ensure stable performance during automatic winding. Product Specification Parameter Specification Product Yellow Mylar Electrical Insulation Tape Backing Material PET / Polyester Film Color Yellow Width 5 mm Length 132 m Adhesive Pressure-Sensitive Adhesive Application High-Frequency Transformer Insulation Application Method Automatic Winding Machine Key Requirement Flatness & Dense Winding Slitting Precision Slitting Roll Specification 5 mm × 132 m Quality Control For this application, conventional tape inspection alone was not sufficient. In addition to standard product inspections, LY paid particular attention to the finished-roll condition. Flatness Inspection The finished tape roll was placed on a horizontal surface to check whether it maintained good contact with the surface. The roll was inspected for: · Deformation · Warping · Lifting · Uneven contact with the horizontal surface Winding Density Inspection The finished roll was visually inspected to ensure that the tape layers were tightly and uniformly wound. Particular attention was given to: · Loose winding · Visible gaps between layers · Uneven winding · Localized protrusion of tape layers Standard Tape Inspection Other key inspection items included: · Thickness · Width · Adhesion / peel strength · Electrical insulation performance · Appearance · Slitting edge quality · Roll winding quality Application Result The 5 mm × 132 m yellow Mylar electrical insulation tape was supplied for use on an automatic winding machine in high-frequency transformer manufacturing. The finished rolls were produced with a flat and dense winding structure according to the customer’s requirements. The controlled winding density helped minimize gaps between tape layers and reduce the risk of tape layers being lifted by airflow during automatic machine operation. The customized roll specification and controlled rewinding process provided a suitable solution for the customer’s automatic winding application. Why Choose LY? Source Manufacturer, Not a Middleman LY is a source manufacturer specializing in industrial electrical insulation tapes. Our manufacturing process includes: Coating → Rewinding → Slitting → Inspection → Packing Because coating, rewinding and slitting are controlled within our manufacturing system, we can adjust production parameters according to different application requirements. For customers using automatic winding equipment, we can focus not only on the basic tape specifications but also on the finished-roll quality and machine application requirements. Customized Electrical Insulation Tape LY provides customized electrical insulation tapes according to customer requirements, including: · PET / Mylar Tape · PI / Kapton Tape · PET Composite Non-Woven Tape · PET Silicone Tape · Fiberglass Cloth Electrical Insulation Tape Customized widths, lengths and roll specifications are available for suitable applications. Applications Yellow Mylar electrical insulation tape can be used in various electrical insulation applications, including: · High-frequency transformer insulation · Transformer winding · Coil insulation · Electrical component insulation · Layer insulation · Barrier insulation · Automatic winding applications Related Products Explore more electrical insulation tape solutions from LY: · PET / Mylar Electrical Insulation Tape · Yellow Mylar Insulation Tape · PI / Kapton Electrical Insulation Tape · PET Composite Non-Woven Tape · PET Silicone Tape · Fiberglass Cloth Electrical Insulation Tape · Transformer Barrier Tape · Margin Tape Looking for Mylar Tape for Automatic Transformer Winding? If you are looking for PET Mylar tape for high-frequency transformer insulation and automatic winding machines, LY can provide customized solutions based on your application requirements. In addition to standard tape properties, we can work with customers on specific requirements for roll flatness, winding density, slitting quality and finished-roll performance. Please send us your: Material + Thickness + Width + Length + Application + Required Quantity Our team can recommend a suitable electrical insulation tape solution for your application. Contact LY for a Customized Transformer Insulation Tape Solution. Email: ftrade2@liangyitape.comWhatsApp: +86 13338711561

Fita Kapton de Poliimida Adesiva de Silicone para Isolamento de Alta Temperatura

Fita de Folha de Alumínio Condutiva Preta para Painel de Display de Motor

Fita de PET Silicone Verde 0.055mm para Revestimento em Pó para Matriz de Pontos LED

Fita de borracha composta da margem 1L da tela não tecida do filme de poliéster

Cortar em matriz Tela de isolamento PET vermelha Alta resistência dielétrica Adesivo acrílico 130°C Resistência à temperatura-RED filme

Fita da isolação do amarelo do filme do ANIMAL DE ESTIMAÇÃO do poliéster, chama - fita elétrica retardadora da isolação

Rolos de filme de poliimida de alto desempenho (filme PI)

Fita de mascaramento de alta temperatura do silicone, única fita de mascaramento adesiva lateral do Polyimide

Fita Kapton de Poliimida Adesiva de Silicone para Isolamento de Alta Temperatura

Fita de Folha de Alumínio Condutiva Preta para Painel de Display de Motor

Fita de PET Silicone Verde 0.055mm para Revestimento em Pó para Matriz de Pontos LED

Fita da isolação do amarelo do filme do ANIMAL DE ESTIMAÇÃO do poliéster, chama - fita elétrica retardadora da isolação

Fita PET Azul Alta Temperatura 155°C Mascaramento para Galvanoplastia e Revestimento

Fita Adesiva de Silicone PET Vermelha – Máscara de 155°C para Pintura e Forno

155°C fita de silicone de poliéster verde mascaramento de alta temperatura para solda de PCB

Fita de Silicone PET Transparente 155°C Mascaramento de Alta Temperatura para Soldagem

Qualidade Fita da isolação do transformador & Fita da isolação da tela Fábrica

fita elétrica adesiva acrílica da prova de calor 130°C com o filme do ANIMAL DE ESTIMAÇÃO de 0.025mm

Fita da isolação da colagem do silicone do filme do Polyimide do *****

Fita de mascaramento cortada elevado desempenho para a pintura de alta temperatura

Fita cortada do Kapton do filme do PI dedo dourado para o mascaramento do revestimento do pó

Fita elétrica da isolação do filme do ANIMAL DE ESTIMAÇÃO do poliéster, fita da isolação do verde da colagem do silicone

Fita elétrica resistente ao calor do dedo dourado para Die Cut que mascara 0.035-0.12 milímetros de espessura

Comprimento amarelo 90m da fita da isolação do motor elétrico do UL

SGS 66m comprimento amarelo poliéster filme de apoio fitas isolantes adesivas
